KWS-AC300 AC Voltmeter Ammeter Power Energy Meter LED Wattmeter Electric with Reset Function 0-100A 50-300V Digital Gauge Meter(AC300 20A)

AmmetersKWS-AC300 AC 50-300V Voltmeter Ammeter KWS Power Energy Meter LED AC Wattmeter Electric Meter with Reset Function 0-100A 40% offModel:AC300-20A:1.Voltage: AC50-300V2.Current: 0-20A3.Power: 0-3000W4.Capacity: 0.01-19999Kwh5.: 0-200H6.Temperature: -10 ° C to 99 ° C7.Package include:1*1 x Meter(10A is without shunt/CT Coil),1*Usuer ManualModel:AC300-100A:1.Voltage: AC50-300V2.Current: 0-100A3.Power: 0-30KW4.Capacity: 0.01-19999Kwh5.: 0-200H6.Temperature: -10 ° C to 99 ° C7.Package include:1*1 x Meter,1 x 100A shunt/CT Coil ,1*Usuer ManualProduct Function:1.Volage curent, power, iming. humilyCurrent electical energy,cumulative electrical energy2. Electic energy and üming can be reset3. Electic energy and iming have power down memory uncion4. Rated frequency 45-65HzOperating Instructions:Click the MENU button on the panel to view the current electrical energyand cumulative electrical energy. Electric energy and reset method: Press and hold the MENU button for 5 seconds, the number in the timingarea will flash, then click the button to select , current electricalenergy and cumulative electrical energy reset. When the number flashes,double-click the button to reset. Press and hold the button for 5 secondsto save the settings.
